HTLB Jaw Coupling

Name: HTLB Jaw Coupling
Brand: Xiamen Kangfuxiang Machinery Co., Ltd
SKU: 126292594

Features of H type jaw coupling:
1.Simple structure, compact dimensions, east to manufacture, low cost, convenient mounting and dismounting
2.Rubber elastomer, high elasticity, long service life
3.Absorb parallel, axial and angular misalignments

Send Inquiry

Description

HTLB jaw coupling

HTLB Jaw Coupling

The metal parts of the H type coupling are made of high quality cast iron GG-25, and its elastomer is made of synthetic rubber, which has a stable transmission of torque and a small embrittlement effect. The H type coupling is widely used in mechanical equipment, such as pump drive system and drive system.

Features of H type jaw coupling:

1.Simple structure, compact dimensions, east to manufacture, low cost, convenient mounting and dismounting

2.Rubber elastomer, high elasticity, long service life

3.Absorb parallel, axial and angular misalignments

HTLB Jaw Coupling

Type	Nominal torque T_n/ N·m	Max speed [n]/r·min^-1	Bore diameter d₁、d₂	Bore length	B	D	D₁	D₂	S	P	Moment of inertia I/ kg·m²	Mass m/kg
Y	J₁
Iron	Steel	L	L₁
HTLB1	160	5000	5000	28	62	44	49	110	80	62	2	33	0.007	6
30、32、35、38	82	60
40、42、45*	112	84
HTLB2	250	4500	32、35、38	82	60	56	125	92	75	38	0.012	9.2
40、42、45、48、50	112	84
HTLB3	355	4000	5000	38	82	60	62	140	100	80	43	0.02	11.2
40、42、45、48、50、55、56	112	84
HTLB4	560	3500	4700	42、45、48、50、55、56	69	160	110	95	47	0.039	17.8
60、63、65*	142	107
HTLB5	900	3100	4200	50、55、56	112	84	74	180	125	108	50	0.072	25.4
60、63、65、70、71、75*	142	107
HTLB6	1400	2800	3800	60、63、65、70、71、75	81	200	140	122	53	0.117	31.3
80、85	172	132
HTLB7	2000	2500	3300	65、70、71、75	142	107	92	225	150	138	61	0.183	43.4
80、85、90*	172	132
HTLB8	2800	2200	3000	71、75	142	107	105	250	165	155	3	69	0.35	58.5
80、85、90、95	172	132
100*	212	167
HTLB9	4000	2000	2700	80、85、90、95	172	132	110	280	180	172	73	0.55	81
100、110*	212	167
HTLB10	5600	1800	2400	90、95	172	132	120	315	200	200	78	0.9	98.9
100、110、120、125	212	167
HTLB11	7100	1600	2100	100、110、120、125	128	350	230	230	83	1.6	152
130、140	252	202
HTLB12	10000	1400	1900	110、120、125	212	167	137	400	250	250	88	2.7	182.8
130、140、150	252	202
HTLB13	12500	1300	1700	120、125	212	167	155	440	265	265	5	99	3.9	204
130、140、150	252	202
160	302	242
HTLB14	16000	1200	1500	130、140、150	252	202	160	480	300	300	104	5.9	277.6
160、170	302	242
HTLB15	20000	1100	1400	140、150	252	202	175	520	315	315	115	8.6	348.3
160、170、180	302	242
HTLB16	28000	1000	1300	160、170、180	201	560	320	320	6	125	13.9	496.9
190、200	352	282
HTLB17	35500	900	1200	170、180	302	242	215	610	352	352	135	20.2	582
190、200、220	352	282
HTLB18	45000	860	1100	180	302	242	234	660	384	384	145	29.7	706.2
190、200、220	352	280
240	410	330
HTLB19	63000	800	1000	200、220	352	280	246	710	416	416	155	43.2	917.2
240、250	410	330
